Model | MS-WIF1D | MS-WIF2D | MS-WIF3D | MS-WIF4D | MS-WIF5D | MS-WIF6D | MS-WIF7D | MS-WIF8D | MS-WIF9D | MS-WIF10D | MS-WIF11D |
---|---|---|---|---|---|---|---|---|---|---|---|
Exterior (D x W x H)(M) | 1.2*1.8*2.2 | 1.5*1.8*2.2 | 1.8*1.8*2.2 | 2*1.8*2.4 | 2*2*2.4 | 2.4*2.4*2.4 | 2.4*3*2.4 | 3*3*2.4 | 3*4*2.4 | 3*5*2.4 | 3*6*2.4 |
Capacity(m³) | 3.2m³ | 4.2m³ | 5.1m³ | 6.3m³ | 7.1m³ | 10.6m³ | 13.3m³ | 17.2m³ | 23.4m³ | 29.6m³ | 35.7m³ |
frequency conversion | Variable frequency | ||||||||||
Doors | Swinger Solid | ||||||||||
Compressor Location | Top or Front | ||||||||||
Refrigeration Type |
Self-Contained |
||||||||||
Energy Consumption (KWhr/day) | 4.81KWH/24H | 4.81KWH/24H | 4.81KWH/24H | 4.81KWH/24H | 9.42KWH/24H | 9.42KWH/24H | 9.42KWH/24H | 13.7KWH/24H | 13.7KWH/24H | 19.5KWH/24H | 19.5KWH/24H |
Electrical Power/ Current | 810W | 810W | 810W | 810W | 1570W | 1570W | 1570W | 2290W | 2290W | 3250W | 3250W |
Number of Shelves /Type | Equipped separately |
SPECIFICATION | CONTENT |
---|---|
rated voltage: | 220 V~240V / 50 Hz Customizable 110V~240V/50-60HZ |
Power Plug/Cord Length | 16A、3M |
Refrigerating system | Air-Cooling |
Compressor brand | Cubigel Can be modified according to needs |
Core Components | Refrigeration Units |
Refrigerant Type | R290 / R507 Can be modified according to needs |
Panel Thickness | 100mm, 200mm, 120mm, 75mm, 150mm |
foaming | cyclopentane |
Refrigeration Type | Self-Contained |
Material | Stainless Steel/ Painted Steel |
temperature control | Electronic temperature controller with display |
Adjustable Set Point Range | -22~15℃ |
Factory Set Point | -18℃ |
Lighting control | Exterior switch-activated interior LED lighting |
Light type | Neutral white LED lighting |
Doors type | Swinger Solid or Glass |
Condensate treatment | Automatic condensate evaporation system |
defrost | defrosting automatic |
Certifications & Compliances | ISO9001、CE Can apply for local national standards |
